KRR1153 is frame wiring harness for SH200-2. Related SH200 excavator wiring harness including KHR1863 cab main wiring harness for SH200A1, KHR1945 wire harness for SH200A2, KHR3189 monitor wire harness for SH200Z3, KHR4028 cabin main wire harness for SH200A3, KRR1071 external wire harness for SH200CT-2, KRR1141 for SH200A2, KRR1599 for SH200-3, KRR1600 for SH200Z3, KRR1783 for SH200-3

Application

KRR1153 is a Sumitomo SH200A2 external wire harness, it would serve as the main electrical backbone connecting the upper structure, cab, engine, and lower chassis. Such a harness routes power and signal circuits for:

• Engine sensors and actuators
• Cab controls and instrument panel
• Lighting and alarm systems
• Hydraulic solenoid valves
• Travel and swing control circuits

Testing and Inspection

If you need a model-specific version, provide the excavator brand/model and the wiring harness section.

1. Before applying power, check continuity, short-to-ground, and pin-to-pin resistance.
2. Reconnect the battery and verify power supply, sensor signals, lights, and controller communication.
3. Check for fault codes. Clear them and recheck after installation.
4. Operate all functions: travel, swing, boom, arm, bucket, and auxiliary hydraulics.
5. Inspect for pulling, rubbing, pinching, or interference through the full working range.
6. After initial operation, re-inspect and re-secure the harness as needed.
